6GK7242-5DX30-0XE0 Siemens SIMATIC S7-1200 communications module CM 1242-5

Product Description:

The 6GK7242-5DX30-0XE0 is the official Siemens CM 1242-5 plug-on communications module, adding a full-featured PROFIBUS DP interface to any SIMATIC S7-1200 CPU. Operating as either DP master (class 1 or 2) or DP slave, it bridges S7-1200 controllers to drives, remote I/O, barcode readers and legacy DP devices at speeds up to 12 Mbps. Compact, snap-on mounting and TIA Portal integration make it the simplest way to modernize or expand machines without replacing existing PROFIBUS infrastructure.

Key Specifications

• Part number (MLFB): 6GK7242-5DX30-0XE0
• Product name: CM 1242-5 communications module
• Compatible CPUs: All S7-1200 CPUs (firmware ≥ V4.0)
• Interface: 1× RS-485, 9-pin D-sub female
• Protocols: PROFIBUS DP-V0 / DP-V1 master & slave, S7 PG/OP, S7 routing
• Baud rates: 9.6 kbps … 12 Mbps, auto-detect
• DP address range: 0–125 (master), 1–125 (slave)
• Max. I/O per master: 512 bytes DI/DO, 128 bytes AI/AO
• Diagnostics: Module & station LEDs, TIA Portal online diagnostics
• Power consumption: 0.5 A from S7-1200 backplane 5 V bus
• Dimensions (W×H×D): 120.00 x 40.00 x 125.00 mm
• Weight: 175 g
• Certifications: CE, UL, cULus, ATEX Zone 2, RCM, RoHS
